How to change requirements for Minimum version of iOS in AppStore

[totebo]

I can’t give an ETA either I’m afraid.

I’ve been asked to set the minimum supported iOS version to 12 for one of my games. Is this still not possible?

[AGulev]

If you want to change it just for the end-user, pls add these two lines into plist:

        <key>MinimumOSVersion</key>
        <string>12.0</string>

This topic is about NE and some limitations, not about the minimum iOS version for the end-user.

[totebo]

Ah, great. Thanks @AGulev!

Edit 1: I copied and pasted the built in Info.plist and changed the 8.0 to 12.0. Testflight didn’t like it:

ERROR ITMS-90474: "Invalid Bundle. iPad Multitasking support requires these orientations: 'UIInterfaceOrientationPortrait,UIInterfaceOrientationPortraitUpsideDown,UIInterfaceOrientationLandscapeLeft,UIInterfaceOrientationLandscapeRight'. Found 'UIInterfaceOrientationPortrait' in bundle 'com.WinkelGames.Juump'."

ERROR ITMS-90475: "Invalid Bundle. Your app supports Multitasking on iPad, so you must include the UILaunchStoryboardName key in your bundle, 'com.WinkelGames.Juump’. Learn more (https://developer.apple.com/library/content/documentation/General/Reference/InfoPlistKeyReference/Articles/iPhoneOSKeys.html#//apple_ref/doc/uid/TP40009252-SW40)."

WARNING ITMS-90747: "Architecture incompatible with MinimumOSVersion. The app bundle at 'JUUMP!.app' specifies a MinimumOSVersion of '12.0' but contains a 32-bit architecture that is unsupported on iOS 12 and later."

I suspect I need to instead use Custom Entitlements, something I haven’t been able to get to work before when adding the ITSAppUsesNonExemptEncryption key.

Using this file as Custom Entitlements:

<?xml version="1.0"?>
<!DOCTYPE plist SYSTEM "file://localhost/System/Library/DTDs/PropertyList.dtd">
<plist version="1.0">
    <dict>
        <key>MinimumOSVersion</key>
        <string>12.0</string>
        <key>ITSAppUsesNonExemptEncryption</key>
        <false/>
    </dict>
</plist>

Produces this error:

If using the custom entitlement file is indeed the ticket to success, how should it be formatted? If not, what’s the solution?

Edit 2: I think a fake extension is the only solution:

Adding ITSAppUsesNonExemptEncryption to Info.plist for iOS builds (SOLVED)

What you can do is to fake an empty extension in your project and add your stub .plist file with the property and let the build server merge it for you.

Adding ITSAppUsesNonExemptEncryption to Info.plist for iOS builds (SOLVED)

I think there’s some confusion around entitlements, the *.mobileprovision file and the Info.plist file. Entitlements An entitlement is a right or privilege that grants an executable particular capabilities. For example, an app needs the HomeKit Entitlement — along with explicit user consent — to access a user’s home automation network. An app stores its entitlements as key-value pairs embedded in the code signature of its binary executable. https://developer.apple.com/documentation/bundlereso…

[AGulev]

If you want to change it just for the end-user, just add these two lines into plist:

        <key>MinimumOSVersion</key>
        <string>12.0</string>

First of all, you need to add these two lines into plist not Entitlements.

1. Find info.plist for iOS in Builtins folder
2. Copy/paste it in your project (anywhere outside of Builtins)
3. Change link to your plist in game.project

After these steps, you will be able to change plist and add your changes there.

Now about your errors/warnings (actually there is enough information about “what to do” ^____^ ):

WARNING ITMS-90747: “Architecture incompatible with MinimumOSVersion. The app bundle at ‘JUUMP!.app’ specifies a MinimumOSVersion of ‘12.0’ but contains a 32-bit architecture that is unsupported on iOS 12 and later.”

Just turn off 32-bit architecture when you bundle iOS (the reason is in message).

ERROR ITMS-90475: “Invalid Bundle. Your app supports Multitasking on iPad, so you must include the UILaunchStoryboardName key in your bundle, 'com.WinkelGames.Juump’. Learn more.”

ERROR ITMS-90474: “Invalid Bundle. iPad Multitasking support requires these orientations: ‘UIInterfaceOrientationPortrait,UIInterfaceOrientationPortraitUpsideDown,UIInterfaceOrientationLandscapeLeft,UIInterfaceOrientationLandscapeRight’. Found ‘UIInterfaceOrientationPortrait’ in bundle ‘com.WinkelGames.Juump’.”

Add the following tag into your plist:

<key>UIRequiresFullScreen</key>
<true/>

ERROR ITMS-90474: “Invalid Bundle. iPad Multitasking support requires these orientations

hi,when i am trying to upload iso bundle to app store,it returns following error package(s) were not uploaded because they had problems: /var/folders/k3/t0kg98ms3n54zx_k1xs7b2yh0000gn/T/A53A0D94-B3A4-4CFC-B63B-8C4D286BFAD6/1470206287.itmsp - Error Messages: ERROR ITMS-90474: “Invalid Bundle. iPad Multitasking support requires these orientations: ‘UIInterfaceOrientationPortrait,UIInterfaceOrientationPortraitUpsideDown,UIInterfaceOrientationLandscapeLeft,UIInterfaceOrientationLandscapeR…

[totebo]

Thanks, will give that a spin tomorrow!

Edit: Testflight accepted the .ipa, after adding this additional key:

<key>UIRequiredDeviceCapabilities</key>
<array>
	...
	<string>arm64</string>
</array>

The next hurdle is this email received shortly after:

Any idea what the value should be here?

[AGulev]

Here is a topic that should help you with ITMS-90713:

How to find bundle icon name - ios release

You are missing <key>CFBundleIconName</key> <string>AppIcon</string> Image should be 1024x1024 though I’m not sure how to set it up properly as I don’t have a Mac in front of me to test.

[totebo]

Thanks @AGulev. I added this key to the Info.plist:

<key>CFBundleIconName</key>
<string>AppIcon</string>

Unfortunately the error came back the same. What to try next?!

Here is the entire Info.plist just in case:

<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN" "http://www.apple.com/DTDs/PropertyList-1.0.dtd">
<plist version="1.0">
<dict>
        <key>BuildMachineOSBuild</key>
        <string>13A603</string>
        <key>CFBundleDevelopmentRegion</key>
        <string>{{ios.default_language}}</string>
        <key>CFBundleDisplayName</key>
        <string>{{project.title}}</string>
        <key>CFBundleExecutable</key>
        <string>{{exe-name}}</string>
        <key>CFBundleIconFiles</key>
        <array>
                <string>Icon-167.png</string>
                <string>Icon-60@3x.png</string>
                <string>Icon-60@2x.png</string>
                <string>Icon-76@2x.png</string>
                <string>Icon-76.png</string>
                <string>Icon@2x.png</string>
                <string>Icon.png</string>
                <string>Icon-72@2x.png</string>
                <string>Icon-72.png</string>
        </array>
        <key>CFBundleIcons</key>
        <dict>
                <key>CFBundlePrimaryIcon</key>
                <dict>
                        <key>CFBundleIconFiles</key>
                        <array>
                                <string>Icon-167.png</string>
                                <string>Icon-60@3x.png</string>
                                <string>Icon-60@2x.png</string>
                                <string>Icon-76@2x.png</string>
                                <string>Icon-76.png</string>
                                <string>Icon@2x.png</string>
                                <string>Icon.png</string>
                                <string>Icon-72@2x.png</string>
                                <string>Icon-72.png</string>
                        </array>
                        <key>UIPrerenderedIcon</key>
                        <{{ios.pre_renderered_icons}}/>
                </dict>
        </dict>
        <key>CFBundleIdentifier</key>
        <string>{{ios.bundle_identifier}}</string>
        <key>CFBundleInfoDictionaryVersion</key>
        <string>6.0</string>
        <key>CFBundleName</key>
        <string>dmengine</string>
        <key>CFBundlePackageType</key>
        <string>APPL</string>
        <key>CFBundleShortVersionString</key>
        <string>{{project.version}}</string>
        <key>CFBundleSignature</key>
        <string>????</string>
        <key>CFBundleSupportedPlatforms</key>
        <array>
                <string>iPhoneOS</string>
        </array>
        <key>CFBundleVersion</key>
        <string>{{project.version}}</string>
        <key>DTCompiler</key>
        <string>com.apple.compilers.llvm.clang.1_0</string>
        <key>DTPlatformBuild</key>
        <string>16B91</string>
        <key>DTPlatformName</key>
        <string>iphoneos</string>
        <key>DTPlatformVersion</key>
        <string>12.0</string>
        <key>DTSDKBuild</key>
        <string>16B91</string>
        <key>DTSDKName</key>
        <string>iphoneos12.1</string>
        <key>DTXcode</key>
        <string>1010</string>
        <key>DTXcodeBuild</key>
        <string>10B61</string>
        <key>UIFileSharingEnabled</key>
        <{{project.write_log}}/>
        <key>LSRequiresIPhoneOS</key>
        <true/>
        <key>UIDeviceFamily</key>
        <array>
                <integer>1</integer>
                <integer>2</integer>
        </array>
        <key>UIStatusBarHidden</key>
        <true/>
        <key>UIViewControllerBasedStatusBarAppearance</key>
        <false/>
        <key>UIRequiredDeviceCapabilities</key>
        <array>
                <string>arm64</string>
                <string>armv7</string>
                <string>opengles-2</string>
        </array>
        <key>CFBundleLocalizations</key>
        <array>{{#application-localizations}}
            <string>{{.}}</string>{{/application-localizations}}
        </array>
        <key>UISupportedInterfaceOrientations</key>
        <array> {{#orientation-support}}
                <string>UIInterfaceOrientation{{.}}</string>{{/orientation-support}}
        </array>
        <key>UISupportedInterfaceOrientations~ipad</key>
        <array> {{#orientation-support}}
                <string>UIInterfaceOrientation{{.}}</string>{{/orientation-support}}
        </array>

        <key>CFBundleURLTypes</key>
        <array>
        </array>

        <key>LSApplicationQueriesSchemes</key>
        <array>
                {{#application-queries-schemes}}<string>{{.}}</string>{{/application-queries-schemes}}
        </array>

        <key>UILaunchImages</key>
        <array>
                <dict>
                    <key>UILaunchImageMinimumOSVersion</key>
                    <string>12.0</string>
                    <key>UILaunchImageName</key>
                    <string>Default</string>
                    <key>UILaunchImageOrientation</key>
                    <string>Portrait</string>
                    <key>UILaunchImageSize</key>
                    <string>{320, 480}</string>
                </dict>
                <dict>
                    <key>UILaunchImageMinimumOSVersion</key>
                    <string>12.0</string>
                    <key>UILaunchImageName</key>
                    <string>Default</string>
                    <key>UILaunchImageOrientation</key>
                    <string>Landscape</string>
                    <key>UILaunchImageSize</key>
                    <string>{320, 480}</string>
                </dict>
                <dict>
                    <key>UILaunchImageMinimumOSVersion</key>
                    <string>12.0</string>
                    <key>UILaunchImageName</key>
                    <string>Default-568h</string>
                    <key>UILaunchImageOrientation</key>
                    <string>Portrait</string>
                    <key>UILaunchImageSize</key>
                    <string>{320, 568}</string>
                </dict>
                <dict>
                    <key>UILaunchImageMinimumOSVersion</key>
                    <string>12.0</string>
                    <key>UILaunchImageName</key>
                    <string>Default-568h</string>
                    <key>UILaunchImageOrientation</key>
                    <string>Landscape</string>
                    <key>UILaunchImageSize</key>
                    <string>{320, 568}</string>
                </dict>
                <dict>
                    <key>UILaunchImageMinimumOSVersion</key>
                    <string>12.0</string>
                    <key>UILaunchImageName</key>
                    <string>Default-Portrait-667h</string>
                    <key>UILaunchImageOrientation</key>
                    <string>Portrait</string>
                    <key>UILaunchImageSize</key>
                    <string>{375, 667}</string>
                </dict>
                <dict>
                    <key>UILaunchImageMinimumOSVersion</key>
                    <string>12.0</string>
                    <key>UILaunchImageName</key>
                    <string>Default-Landscape-667h</string>
                    <key>UILaunchImageOrientation</key>
                    <string>Landscape</string>
                    <key>UILaunchImageSize</key>
                    <string>{375, 667}</string>
                </dict>
                <dict>
                    <key>UILaunchImageMinimumOSVersion</key>
                    <string>12.0</string>
                    <key>UILaunchImageName</key>
                    <string>Default-Portrait-736h</string>
                    <key>UILaunchImageOrientation</key>
                    <string>Portrait</string>
                    <key>UILaunchImageSize</key>
                    <string>{414, 736}</string>
                </dict>
                <dict>
                    <key>UILaunchImageMinimumOSVersion</key>
                    <string>12.0</string>
                    <key>UILaunchImageName</key>
                    <string>Default-Landscape-736h</string>
                    <key>UILaunchImageOrientation</key>
                    <string>Landscape</string>
                    <key>UILaunchImageSize</key>
                    <string>{414, 736}</string>
                </dict>
                <dict>
                    <key>UILaunchImageMinimumOSVersion</key>
                    <string>12.0</string>
                    <key>UILaunchImageName</key>
                    <string>Default-Portrait-1024h</string>
                    <key>UILaunchImageOrientation</key>
                    <string>Portrait</string>
                    <key>UILaunchImageSize</key>
                    <string>{768, 1024}</string>
                </dict>
                <dict>
                    <key>UILaunchImageMinimumOSVersion</key>
                    <string>12.0</string>
                    <key>UILaunchImageName</key>
                    <string>Default-Landscape-1024h</string>
                    <key>UILaunchImageOrientation</key>
                    <string>Landscape</string>
                    <key>UILaunchImageSize</key>
                    <string>{768, 1024}</string>
                </dict>
                <dict>
                    <key>UILaunchImageMinimumOSVersion</key>
                    <string>12.0</string>
                    <key>UILaunchImageName</key>
                    <string>Default-Portrait-1112h</string>
                    <key>UILaunchImageOrientation</key>
                    <string>Portrait</string>
                    <key>UILaunchImageSize</key>
                    <string>{834,1112}</string>
                </dict>
                <dict>
                    <key>UILaunchImageMinimumOSVersion</key>
                    <string>12.0</string>
                    <key>UILaunchImageName</key>
                    <string>Default-Landscape-1112h</string>
                    <key>UILaunchImageOrientation</key>
                    <string>Landscape</string>
                    <key>UILaunchImageSize</key>
                    <string>{834,1112}</string>
                </dict>
                <dict>
                    <key>UILaunchImageMinimumOSVersion</key>
                    <string>12.0</string>
                    <key>UILaunchImageName</key>
                    <string>Default-Portrait-1366h</string>
                    <key>UILaunchImageOrientation</key>
                    <string>Portrait</string>
                    <key>UILaunchImageSize</key>
                    <string>{1024,1366}</string>
                </dict>
                <dict>
                    <key>UILaunchImageMinimumOSVersion</key>
                    <string>12.0</string>
                    <key>UILaunchImageName</key>
                    <string>Default-Landscape-1366h</string>
                    <key>UILaunchImageOrientation</key>
                    <string>Landscape</string>
                    <key>UILaunchImageSize</key>
                    <string>{1024,1366}</string>
                </dict>
                <dict>
                    <key>UILaunchImageMinimumOSVersion</key>
                    <string>12.0</string>
                    <key>UILaunchImageName</key>
                    <string>Default-Portrait-812h</string>
                    <key>UILaunchImageOrientation</key>
                    <string>Portrait</string>
                    <key>UILaunchImageSize</key>
                    <string>{375, 812}</string>
                </dict>
                <dict>
                    <key>UILaunchImageMinimumOSVersion</key>
                    <string>12.0</string>
                    <key>UILaunchImageName</key>
                    <string>Default-Landscape-812h</string>
                    <key>UILaunchImageOrientation</key>
                    <string>Landscape</string>
                    <key>UILaunchImageSize</key>
                    <string>{375, 812}</string>
                </dict>
        </array>
        <key>ITSAppUsesNonExemptEncryption</key>
        <false/>
        <key>MinimumOSVersion</key>
        <string>12.0</string>
        <key>UIRequiresFullScreen</key>
        <true/>
        <key>CFBundleIconName</key>
        <string>AppIcon</string>
</dict>
</plist>

[AGulev]

Unfortunately the error came back the same. What to try next?!

Unfortunately, I can’t check everything myself but pls, take a look this link:

Revisions to Missing CFBundleIconName in Xcode9 iOS11 app release

Also, this instruction may be useful for you:

[totebo]

Blimey, I really did open a can of worms. REVERT! I may come back to this at a later date. Thanks for all your help @AGulev.
