(SOLVED) White background/border/outline on HTML5 instant facebook build

Hi guys I just deploy my build on instant facebook game to check how it is going.
I did remove this part from index.html

     <div class="buttons-background">
        <div class="button" onclick="Module.toggleFullscreen();">
         Fullscreen
        </div>
        <div class="link">
         Made with
         <a href="https://defold.com/" target="_blank">Defold</a>
        </div>
       </div>

Here is my index.html

    <!doctype html>
    <html lang="en">
     <head>
      <meta charset="utf-8">
      <meta http-equiv="X-UA-Compatible" content="IE=edge,chrome=1">
      <meta name="viewport" content="width=device-width, initial-scale=1.0, maximum-scale=1.0, user-scalable=0, minimal-ui, shrink-to-fit=no">
      <meta name="apple-mobile-web-app-capable" content="yes">
      <!-- The above 4 meta tags *must* come first in the head; any other head content must come *after* these tags -->
      <title>nyan-cat-runner 1.0</title>
      <style type="text/css">
    	/* Disable user selection to avoid strange bug in Chrome on Windows:
    	* Selecting a text outside the canvas, then clicking+draging would
    	* drag the selected text but block mouse down/up events to the engine.
    	*/
    	body {
    		position: fixed; /* Prevent overscroll */

    		margin:0;
    		padding:0;
    	}

    	.canvas-app-container {
    		width: 100%;
    		height: 100%;
    		position: absolute;
    		align-items: center;
    		justify-content: center;
    		overflow: hidden;
    	}

    	.canvas-app-container:-webkit-full-screen {
    		/* Auto width and height in Safari/Chrome fullscreen. */
    		width: auto;
    		height: auto;
    	}

    	#canvas {
    		outline: none;
    		border: 0;
    		width: 100%;
    		vertical-align: bottom;
    	}

    	canvas:focus, canvas:active {
    		outline: none;
    		border: 0;
    		ie-dummy: expression(this.hideFocus=true);
    		-moz-outline-style: none;
    	}

    	div {
    		-webkit-tap-highlight-color: rgba(0,0,0,0);
    		-webkit-touch-callout: none;
    		-webkit-user-select: none;
    		-khtml-user-select: none;
    		-moz-user-select: none;
    		-ms-user-select: none;
    		user-select: none;
    	}

    		.canvas-app-progress {
    		position: absolute;
    		background-color: #d1dbeb;
    		height: 6px;
    		margin-top: -6px;
    		width: 100%;
    	}

    	.canvas-app-progress-bar {
    		font-size: 12px;
    		height: 6px;
    		color: rgb(255, 255, 255);
    		background-color: #1a72eb;
    		text-align: center;
    		line-height: 20px;
    	}

    	.button {
    		background-repeat: no-repeat;
    		border-color: transparent;
    		float: left;
    		color: #006fff;
    		padding-left: 50%;
    		padding: 0px 0px 0px 20px;
    		cursor:pointer;
    		background-position: left bottom;
    		margin-left: 2px;
    	}
    	.link {
    		text-align: right;
    		color: #4e5258;
    		margin-right: 2px;
    	}
    	a {
    		font-weight: 600;
    		color: #006fff;
    		text-decoration: none;
    	}
    	.link, .button {
    		font-family: sans-serif;
    		font-size: 14px;
    		font-weight: normal;
    		font-style: normal;
    		font-stretch: normal;
    		line-height: normal;
    		letter-spacing: 0px;
    		padding-top: 12px;
    	}

    	.buttons-background {
    		background-color: #ffffff;
    		width: 100%;
    		height: 42px;
    	}

    	body {
    		background-color: #ffffff;
    	}

    	.canvas-app-container {
    		background: rgba(250,252,255,1);
    		background: -moz-linear-gradient(-45deg, rgba(250,252,255,1) 0%, rgba(250,252,255,1) 50%, rgba(245,249,255,1) 50%, rgba(245,249,255,1) 100%);
    		background: -webkit-gradient(left top, right bottom, color-stop(0%, rgba(250,252,255,1)), color-stop(50%, rgba(250,252,255,1)), color-stop(50%, rgba(245,249,255,1)), color-stop(100%, rgba(245,249,255,1)));
    		background: -webkit-linear-gradient(-45deg, rgba(250,252,255,1) 0%, rgba(250,252,255,1) 50%, rgba(245,249,255,1) 50%, rgba(245,249,255,1) 100%);
    		background: -o-linear-gradient(-45deg, rgba(250,252,255,1) 0%, rgba(250,252,255,1) 50%, rgba(245,249,255,1) 50%, rgba(245,249,255,1) 100%);
    		background: -ms-linear-gradient(-45deg, rgba(250,252,255,1) 0%, rgba(250,252,255,1) 50%, rgba(245,249,255,1) 50%, rgba(245,249,255,1) 100%);
    		background: linear-gradient(135deg, rgba(250,252,255,1) 0%, rgba(250,252,255,1) 50%, rgba(245,249,255,1) 50%, rgba(245,249,255,1) 100%);
    		filter: progid:DXImageTransform.Microsoft.gradient( startColorstr='#fafcff', endColorstr='#f5f9ff', GradientType=1 );
    	}

    	.canvas-app-canvas {
    		background-repeat:no-repeat;
    		background-position: center center;
    		background-size: 70%;
    	}
    	</style>
      <style>

        .canvas-app-progress {
            visibility: hidden;
        }

        .canvas-app-progress-bar {
            visibility: hidden;
        }
        </style>
     </head>
     <body oncontextmenu="return false;">
      <div id="app-container" class="canvas-app-container">
       <canvas id="canvas" class="canvas-app-canvas" tabindex="1" width="1366" height="768"></canvas>
       <div class="buttons-background">
        <div class="button" onclick="Module.toggleFullscreen();">
         Fullscreen
        </div>
        <div class="link">
         Made with
         <a href="https://defold.com/" target="_blank">Defold</a>
        </div>
       </div>
      </div>
      <!-- -->
      <script id="engine-loader" type="text/javascript" src="dmloader.js"></script>
      <!-- -->
      <script id="engine-setup" type="text/javascript">
    	var extra_params = {
    		archive_location_filter: function( path ) {
    			return ("archive" + path + "");
    		},
    		engine_arguments: [],
    		custom_heap_size: 268435456,
    		disable_context_menu: true
    	}

    	Module['onRuntimeInitialized'] = function() {
    		Module.runApp("canvas", extra_params);
    	};

    	Module["locateFile"] = function(path, scriptDirectory)
    	{
    		// dmengine*.wasm is hardcoded in the built JS loader for WASM,
    		// we need to replace it here with the correct project name.
    		if (path == "dmengine.wasm" || path == "dmengine_release.wasm" || path == "dmengine_headless.wasm") {
    			path = "nyancatrunner.wasm";
    		}
    		return scriptDirectory + path;
    	};

    	var is_iOS = /iPad|iPhone|iPod/.test(navigator.userAgent) && !window.MSStream;
    	var buttonHeight = 0;
    	buttonHeight = 42;
    	buttonHeight = 42;
    	// Resize on init, screen resize and orientation change
    	function resize_game_canvas() {
    		// Hack for iOS when exit from Fullscreen mode
    		if (is_iOS) {
    			window.scrollTo(0, 0);
    		}

    		var app_container = document.getElementById('app-container');
    		var game_canvas = document.getElementById('canvas');
    		var innerWidth = window.innerWidth;
    		var innerHeight = window.innerHeight - buttonHeight;
    		var width = 1366;
    		var height = 768;
    		var targetRatio = width / height;
    		var actualRatio = innerWidth / innerHeight;

    		//Downscale fit
    		if (innerWidth < width || innerHeight < height) {
    			if (actualRatio > targetRatio) {
    				width = innerHeight * targetRatio;
    				height = innerHeight;
    				app_container.style.marginLeft = ((innerWidth - width) / 2) + "px";
    				app_container.style.marginTop = "0px";
    			}
    			else {
    				width = innerWidth;
    				height = innerWidth / targetRatio;
    				app_container.style.marginLeft = "0px";
    				app_container.style.marginTop = ((innerHeight - height) / 2) + "px";
    			}
    		}
    		else {
    			app_container.style.marginLeft = ((innerWidth - width) / 2) + "px";
    			app_container.style.marginTop = ((innerHeight - height) / 2) + "px";
    		}




    		app_container.style.width = width + "px";
    		app_container.style.height = height + buttonHeight + "px";
    		game_canvas.width = width;
    		game_canvas.height = height;
    	}
    	resize_game_canvas();
    	window.addEventListener('resize', resize_game_canvas, false);
    	window.addEventListener('orientationchange', resize_game_canvas, false);

    	function load_engine() {
    		var engineJS = document.createElement('script');
    		engineJS.type = 'text/javascript';
    		if (Module['isWASMSupported']) {
    			engineJS.src = 'nyancatrunner_wasm.js';
    		} else {
    			engineJS.src = 'nyancatrunner_asmjs.js';
    		}
    		document.head.appendChild(engineJS);
    	}
    	</script>
      <script id="engine-start" type="text/javascript">
    		load_engine();
    	</script>
      <script src="https://connect.facebook.net/en_US/fbinstant.6.3.js"></script>
      <script type="text/javascript">
            // Set up a progress listener and feed progress to FBInstant
            Progress.updateProgress = function (percentage, text) {
                FBInstant.setLoadingProgress(percentage);
            }

            // Do early initialization of FBInstant
            // This is required to be able to properly update the loading
            // progress above.
            FBInstant.initializeAsync().then(function() {
                // This will be checked by the FBInstant Defold extension
        		Module._fbinstant_inited = true;
        	});
        </script>
     </body>
    </html>

Here is the result

if you want to remove Fullscreen and Made with Defold buttons, you have checkboxes for that in game.project in HTML5 section.

4 Likes

It should be possible to inspect the elements and see what is causing the white space, even on mobile devices you can attach an inspector usually.

2 Likes

Thanks for this @AGulev. Seems I missed this out from manual.
Definitely I will try to inspect the elements. @Pkeod :+1:

2 Likes
