Defold 1.7.0
The latest beta is now released, and we invite those interested in beta testing the new features in the editor and engine to join now.
The beta period will be 2 weeks and the next planned stable release is two weeks from now.
We hope this new workflow will highlight any issues earlier, and also get valuable feedback from our users. And please comment if you come up with ideas on improving on this new workflow.
Please report any engine issues in this thread or in issues using Help → Report Issue
Thx for helping out!
Disclaimer
This is a BETA release, and it might have issues that could potentially be disruptive for you and your teams workflow. Use with caution. Use of source control for your projects is strongly recommended.
Access to the beta
Download the editor or bob.jar from http://d.defold.com/beta/
Release notes
As the version number suggests, in this version we have introduced some breaking changes.
The more important changes are related to texture mip map options, and also the removal of the system_font from the builtins package.
Please read those sections extra carefully.
There is also some “code cleanup” that may strictly be considered a breaking change. It relates to us removing old extension stubs.
It shouldn’t affect anyone, as these extensions have been published to github and been in use for many years.
Summary
-
BREAKING CHANGE: (#8528) More options for min filter in
game.project→Graphics→Default Texture Min Filter - BREAKING CHANGE: (#8548) Removed deprecated extensions from the code
-
BREAKING CHANGE: (#8559) Removed
system_font.fontfrombuiltins -
BREAKING CHANGE: (#8529) Turn mipmaps off in the
default.texture_profilesfile inbuiltins - BREAKING CHANGE: (#8553) Removed old deprecated messages
- NEW: (#8424) Render target as a resource
- NEW: (#8322) Increased length of debug prints for urls to 256 per part and 512 in total
-
NEW: (#8513) Add missed
gui.BLEND_SCREENconstant intoguimodule - NEW: (#8525) Add camera focus message’s wrappers.
- NEW: (#8562) Set custom vertex data API (Sprites)
- NEW: (#8577) Add support for enabling a render target resource in render.enable_texture
- NEW: (#8599) Flip image flag for image.load
- NEW: (#8521) Add world to local coordinate system conversion API
-
NEW: (#8473) Add
editor.delete_directory() - NEW: (#8510) Use async engine build in the editor
- FIX: (#8371) Fix http request timeout usage in HTML5 build
-
FIX: (#8477) Fix issue when profiler show wrong count of
GUI.ActiveNodes - FIX: (#8486) Fixed an issue where the game wouldn’t start if the iframe didn’t allow gamepad usage (HTML5).
- FIX: (#8484) Fix multi-buffered render buffers on non-opengl graphics adapters
- FIX: (#8496) Fixed an issue where attempting to use IndexedDB when it is prohibited prevents game loading in HTML5.
- FIX: (#8493) Fix for crash caused by ray casting followed by deletion of the object
- FIX: (#8305) add “Support texture handles in render.enable_texture” mention to API documentation
-
FIX: (#8544) Send
sound_doneorsound_stoppedmessages only if the sound is played usingmsg.post()with theplay_idparameter. -
FIX: (#8551) Fixed an issue where
bob.jardid not delete some temporary folders after the bundling process was completed. - FIX: (#8552) Support sampler names in render.enable_texture
- FIX: (#8582) Crash fixes for the GDC tool
- FIX: (#8567) Fixed rendering of untextured sprites in the editor
- FIX: (#8569) Added support for sprite to not have a texture assigned
- FIX: (#8579) Check that texture width and height is valid before creating texture
- FIX: (#8583) Use correct material tag for mesh components
-
FIX: (#8591) Add
retry_countandretry_timesettings to thegame.projectfile in thehtml5section. -
FIX: (#8547) Fix issues with
physics.set_shape()whenAllow Dynamic Transformsis on - FIX: (#8561) Fixed the way the HTML5 bundler splits and renames resource files
- FIX: (#8545) Add arm64-osx platform to manifests
- FIX: (#8522) Graph successor memory optimizations
-
FIX: (#8531) Hide texture formats and texture compressions from
*.textures_profilesthat are currently not supported. - FIX: (#8563) Properly validate sprite texture assignments
- FIX: (#8593) Paged atlas preview bugfix
Engine
BREAKING CHANGE: (#8528) More options for min filter in game.project → Graphics → Default Texture Min Filter
Now, the field Default Texture Min Filter in game.project → Graphics has the same options as materials do.
This is a breaking change for projects that use mipmaps on their textures and the OpenGL graphics backend.
Old behavior was:
- Options
linearandnearestasDefault Texture Min FiltermeantTEXTURE_FILTER_LINEAR_MIPMAP_NEARESTandTEXTURE_FILTER_NEAREST_MIPMAP_NEARESTrespectively. - If a texture without mipmaps was used with a material where
Min Filterwas specified with mipmaps, it used theMag Filteroption instead.
Current behavior:
- Options
linearandnearestasDefault Texture Min FiltermeanTEXTURE_FILTER_LINEARandTEXTURE_FILTER_NEARESTrespectively. - If a texture without mipmaps is used with a material where
Min Filteris specified with mipmaps, it simply ignores the mipmaps part of the filter. For example, forTEXTURE_FILTER_LINEAR_MIPMAP_NEAREST, it will beTEXTURE_FILTER_LINEAR, etc.
BREAKING CHANGE: (#8548) Removed deprecated extensions from the code
In this release we’ve removed old extension stubs for facebook, iap, iac, push and webview.
This shouldn’t affect any users, but is only part of an internal code cleanup task.
The actual extensions are found in the github repositories (e.g. GitHub - defold/extension-iap: In-app purchase extension for Defold)
BREAKING CHANGE: (#8559) Removed system_font.font from builtins
This breaking change was implemented to clarify the usage of predefined fonts in builtins. The old system_font.font has been completely removed from the builtins, and two new fonts have been introduced:
-
builtins/fonts/default.font, which uses the default df material and can serve as a font for the development process. -
builtins/fonts/debug/always_on_top.font, which utilizes a special materialbuiltins/fonts/debug/always_on_top_font.materialwith thedebug_texttag. This font is intended to be drawn on top of other elements and is used for debugging purposes (such as the profiler and thedraw_debug_textmessage) as replacement of oldsystem_font.font. Additionally, changes are required indefault.render_script, where the oldtextpredicate has been replaced with thedebug_textpredicate for clarity.
BREAKING CHANGE: (#8529) Turn mipmaps off in the default.texture_profiles file in builtins
This is a breaking change for projects that use default.texture_profiles from the builtins folder.
If you need mipmaps for your textures, ensure you use a custom default.texture_profiles where this option is enabled.
BREAKING CHANGE: (#8553) Removed old deprecated messages
The following messages were removed:
-
msg.post(url, "request_transform")and"transform_response"– requests the transform from an instance -
msg.post(url, "set_tile", ...)– usetilemap.set_tile()instead
NEW: (#8424) Render target as a resource
A new resource type has been added that creates render targets that can be used as a regular texture in the engine.
The .render file has also been refactored to support this new render resource type. You can now add .render_target files into the render prototype resource. In the render_script, you can use these render targets in the same way as before, except that you can now pass in the render resource name when binding the render target:
-- in a render script:
render.set_render_target("my_rt")
A new function has also been added to .script files to get all the metadata about a render target resource:
resource.get_render_target_info(path)
NEW: (#8322) Increased length of debug prints for urls to 256 per part and 512 in total
NEW: (#8513) Add missed gui.BLEND_SCREEN constant into gui module
Added gui.BLEND_SCREEN, which was missing in the documentation as well as in the gui module.
NEW: (#8525) Add camera focus message’s wrappers.
Now it possible to activate/deactivate camera component via camera.acquire_focus/ camera.release_focus.
camera.acquire_focus("/observer#main_camera")
camera.release_focus("/observer#main_camera")
NEW: (#8562) Set custom vertex data API (Sprites)
Added support for setting and getting vertex attributes for sprites via the go.set, go.get and go.animate functions. Similar to shader constants, the attributes has to be specified in the material:
To modify the my_color attribute:
local my_color = go.get("#sprite", "my_color")
my_color.x = my_color.x + 0.5
go.set("#sprite", "my_color", my_color)
Or alternatively, you can use go.animate:
go.animate("#sprite", "my_color", go.PLAYBACK_LOOP_FORWARD, vmath.vector4(1, 0, 0, 1), go.EASING_INBACK, i))
NEW: (#8577) Add support for enabling a render target resource in render.enable_texture
Render script can now enable render targets specified in the Render Resource table in a .render file:
This can now be done by calling render.enable_texture:
-- draw something to a render target:
render.set_render_target("rt_res")
-- do drawing here and unbind RT
render.set_render_target(render.RENDER_TARGET_DEFAULT)
-- set the RT buffer 0 to a sampler and draw something using it
render.enable_texture("my_sampler", "rt_res", render. BUFFER_COLOR0_BIT)
render.draw(self.my_predicate)
NEW: (#8599) Flip image flag for image.load
image.load and image.load_buffer can now flip images vertically when loading:
image.load_buffer(path, { flip_vertically = true })
image.load(path, { flip_vertically = true })
Note that the second argument will now accept an option table, with these arguments:
premultiply_alpha - True if alpha should be premultiplied into the color components. Defaults to `false`.
flip_vertically - True if the image contents should be flipped vertically. Defaults to `false`.
NEW: (#8521) Add world to local coordinate system conversion API
Add new APIs to convert world position and world transform to game object’s coordinate space.
How to use:
local test_pos = go.get_world_position("/test")
local child_pos = go.get_world_position("/child")
local new_position = go.world_to_local_position(test_pos, "/child")
local test_transform = go.get_world_transform("/test")
local child_transform = go.get_world_transform("/child")
local result_transform = go.world_to_local_transform(test_transform, "/child")
FIX: (#8371) Fix http request timeout usage in HTML5 build
- Fix timeout option usage in http module for HTML5 implementation.
- Update
httpmodule documentation. - Wrap
HttpRequestAsyncarguments with struct. - Fix possible memory leak.
FIX: (#8477) Fix issue when profiler show wrong count of GUI.ActiveNodes
Fixed an issue where nodes that aren’t directly disabled, but are disabled because one of their parents is disabled in the tree, were incorrectly counted in GUI.ActiveNodes by the profiler.
FIX: (#8486) Fixed an issue where the game wouldn’t start if the iframe didn’t allow gamepad usage (HTML5).
Fixed the issue where the game doesn’t start if access to gamepads is disallowed by the permissions policy.
FIX: (#8484) Fix multi-buffered render buffers on non-opengl graphics adapters
We have fixed an issue with models when using a multi-buffered render setup. This should have no effect on OpenGL-based rendering, but is important for console and vulkan adapters.
FIX: (#8496) Fixed an issue where attempting to use IndexedDB when it is prohibited prevents game loading in HTML5.
Fixed an issue where, in some rare cases, if IndexedDB usage is restricted, users may encounter the “Assertion failed: IDBFS used, but IndexedDB not supported” error.
FIX: (#8493) Fix for crash caused by ray casting followed by deletion of the object
Fixed a crash that occurs if physics.raycast_async() is called in the on_message() function and then the object is deleted immediately.
FIX: (#8305) add “Support texture handles in render.enable_texture” mention to API documentation
For now there is no mention to support handles except a rendertarget handle:
But since 1.4.6 we have support texture handles:
-- in a regular gameobject script:
local my_texture_info = resource.get_texture_info("/my_atlas.a.texturesetc")
msg.post("@render:", "set_my_texture", { handle = my_texture_info.handle })
-- in a render script:
function update(self, dt)
render.enable_texture(0, self.my_texture)
end
function on_message(self, message_id, message)
if message_id == hash("set_my_texture") then
self.my_texture = message.handle
end
end
FIX: (#8544) Send sound_done or sound_stopped messages only if the sound is played using msg.post with the play_id parameter.
The sound component will send sound_done and sound_stopped messages only if msg.post() is used with the play_id parameter, as in msg.post("#sound", "play_sound", {play_id = 1}).
FIX: (#8551) Fixed an issue where bob.jar did not delete some temporary folders after the bundling process was completed.
Fixed an issue where, in some cases, bob.jar did not delete temporary folders. This could quickly fill up the disk on a CI machine.
FIX: (#8552) Support sampler names in render.enable_texture
Added support for enabling and disabling a sampler by a string or hash in a render script:
render.enable_texture(unit|name|hash, texture)
render.disable_texture(unit|name|hash, texture)
Previously a texture could only be bound to the renderer by texture units, which could cause issues when certain graphics adapters optimizes away unbound textures. With this new functionality, you can bind the same textures to multiple sampler names, which will be bound to the matching sampler name by the renderer when draw calls are issued:
render.enable_texture("my_global_texture", self.tex0)
render.enable_texture("some_other_sampler", self.tex0)
render.enable_texture("a_third_sampler", self.tex0)
It’s however recommended that you use the same sampler name for all samplers in this case, this example just illustrates that it is possible to do so!
FIX: (#8582) Crash fixes for the GDC tool
Fixed an issue where the GDC tool would crash immediately after starting. This is due to recent changes to our platform layer.
FIX: (#8567) Fixed rendering of untextured sprites in the editor
Untextured sprites now show up in the editor viewport as long as their shader renders something.
FIX: (#8569) Added support for sprite to not have a texture assigned
This fixes an issue where the engine crashed if the sprite had no textures at all.
Now, the UV coordinates will encompass the entire sprite (since it has no atlas).
FIX: (#8579) Check that texture width and height is valid before creating texture
Calling resource.create_texture() with a width and/or height of zero crashed the engine. This change will check that the width and height are valid and throw a Lua error otherwise.
FIX: (#8583) Use correct material tag for mesh components
Fixed an issue where the wrong material tag was using when producing render lists.
FIX: (#8591) Add retry_count and retry_time settings to the game.project file in the html5 section.
Two new settings are available in the game.project file in the html5 section:
-
retry_count: how many attempts the engine makes when trying to download a file. -
retry_time: pause in seconds before retrying file loading after an error.
The default template
builtins/manifests/web/engine_template.htmlhas been changed. If you use your own custom template, make sure to update it with these changes.
FIX: (#8547) Fix issues with physics.set_shape() when Allow Dynamic Transformsis on.
Fix issues with physics.set_shape() which appears when Allow Dynamic Transforms option in game.project is on.
FIX: (#8561) Fixed the way the HTML5 bundler splits and renames resource files
Instead of using names like game.arcd0 , game.arcd1 , game.arci0 for resource files in the HTML5 bundle, this fix keeps the file extension as is and adds filename counters instead: game0.arcd , game1.arcd , game0.arci . This will facilitate the use of custom server settings for files based on their filetype.
FIX: (#8547) Add arm64-osx platform to manifests
Add arm64-osx platform to release/headless manifests.
Fix js-web excludeLibs list.
Editor
NEW: (#8473) Add editor.delete_directory()
NEW: (#8510) Use async engine build in the editor
The editor now uses async build server API. This should help with timeouts for long engine builds caused by big extensions.
FIX: (#8522) Graph successor memory optimizations
Large projects with a lot of connections will now use significantly less memory.
FIX: (#8531) Hide texture formats and texture compressions from *.textures_profiles that are currently not supported.
All the unsupported texture formats and texture compressions are hidden from *.texture_profiles.
FIX: (#8563) Properly validate sprite texture assignments
- Fixes a regression where you could build the project without properly assigning textures to all samplers in the assigned sprite material.
- Fixes an issue where the sprite animation dropdown would contain entries for the non-primary atlas if any sampler apart from the first one was assigned first.
- Mismatches between paged and unpaged materials and textures are now properly reported as build errors for sprites.
FIX: (#8593) Paged atlas preview bugfix
…It seems that the reports about it in last release’s thread were because it was still broken, not because it suddenly worked flawlessly. It is directly stated in the Sound manual that you can delete the game object that a sound component is on and it should still work fine.
