Yeah, it’s in our roadmap. Not sure when we’ll tackle it, but if I’m guessing it’s somewhere in December or January.
6 Likes
Hi! When are you planning on fixing the issue(batching tint and other)?
1 Like
We mentioned custom vertex formats in our most recent Roadmap Post. We’re slightly behind in terms of what we had hoped to deliver by now due to in part some stability issues during the autumn and in part because of internal needs that was given higher priority. The roadmap post is still accurate, but I will post an update in beginning of January with some updates.
5 Likes
any news?
2 Likes
News on custom vertex formats or on the roadmap (there was a new roadmap post made in January as promised)?
1 Like
News about this:
as I understood “custom vertex formats” solve this.
3 Likes
I’d like to hear some clarifications on this amazing post, namely if and how the situation changes when using custom render predicates / materials / shaders, since if I understand it correctly, this guide assumes that the builtins are used everywhere.
Would different component types break batching if they were to use the same material? Or different materials but the same rendering predicate?
Do different materials break batching by themselves, or is it ultimately because they use different shaders?
Tint is explicitly said to break batching (as long as the values are not the same), but I assume this goes for any other custom constant I might be using, right?
Does this apply only to fragment shaders, or do different vertex shader constant values also break batching?
Thanks for any insight you can give me.
2 Likes
The batch rules are documented here:
2 Likes
Ah, interesting. I didn’t realize the z level comes into play like it sort-of does in gui, but there it can be solved by layers.
So a tinted sprite on z level 0 will prevent batching of non-tinted sprites on levels 0.5 and -0.5, right?
I think I can save some draw calls in my current project when rendering a light map - I can group lights with the same tint on the same z level and put all the ones using other variable shader constants “aside” so they don’t break anything.
Thanks!
2 Likes
Also we can set few lights sources as constant_buffer for whole predicate (‘tile’ for example) and then calculate light intensity in the sprite/other component shader.
Or render lights into texture in renderscript and use it as lightmap texture in sprite shader, calculating tinting on sprite position within lightmap. So, this way prevents from setting tint to each sprites.
4 Likes
One part is still not clear to me - Why does the difference in shader constants break batching?
One part is still not clear to me - Why does the difference in shader constants break batching?
We need to send the shader constants (uniforms) before each draw call.
(Yes, there are uniform buffers, but we also still support older OpenGL versions. And uniform buffers don’t exist in OpenGLES)
2 Likes
It makes sense now. Thanks a lot
